DOMETIC Eskimo Ice Maker EI540X-2451 with Digital Controller

Eskimo Ice EI540X is available in a smaller version package for boats with less space but a big demand for daily ice output. A cube-shaped package with a footprint of only 16.25 x 16.25 in. (413 x 413 mm), the EI540X makes up to 540 lbs. (245 kg) of ice per day.

Ice is generated within minutes after starting the unit, and can be conveyed up to 35 ft/10.6 m through an ice-delivery hose to nearly any desired location on board.

Titanium durability extends the service life of the condenser for many years of worry-free operation. This is because titanium is unaffected by the punishing combination of saltwater, invasive marine life, and the harsh acids used for routine cleaning of the condenser coil.

The system is operated by the Smart Logic control. The control is integrated into the electrical box which can be mounted remotely for installation flexibility. Smart Logic features a full menu of sensors and status lights to monitor gas pressure, auger motor, compressor, water level, ice level, and ice clogs, and will shut off the system if problems are detected.

The EI540X system installation kit includes one electrical box with Smart Logic keypad/display, water filter, and 35 ft/10.6 m of 0.75 in/20 mm ID ice delivery hose and insulation. This smaller diameter hose is easier to install and less likely to kink. The EI540X will support an additional remotely-mountable Smart Logic keypad/display, which can be purchased separately.

• Produces up to 540 lbs. (245 kg) of fishbox ice per day
• Conveys ice 35 ft/10.6 m through insulated delivery hose
• Available in 115V/60Hz, 230V/60Hz, and 220V/50Hz
• Titanium durability extends service life of the system
• Thermal expansion valve increases performance for all conditions
• Ventilated cover panels can be removed for maintenance access from any side
• Monitor system and restart from any Smart Logic digital control location
• CAN Bus compatible
• Optional STIIC access
